Features:
Designed and widely applied for public pools
Fast return on investment
Heating & Cooling function
Inverter system
Corrosion proof titanium heat exchange Long life span
Multiple system protections-Safe and reliable operation
World brand compressor
Self-diagnosis-Displaying error code on control panel
Galvanized powered coated steel cabinet
Anti-freezing Protection
Higher Efficient:Heating/Cooling
By utilizing 4 ways valve, provide both heating and cooling mode to create more possibility for pool enjoyment.
Inverter Technology
Intelligent Inverter tech will keep the constant water temperature automatically, a much more convenient swimming experience than an ON/OFF system.
Eco Friendly Refrigerant R32
Compared to the refrigerants widely used today, such as R22 and R410a, R32 has a global warming potential that is two-third lower and it is remarkable for its low environmental impact, which speed up the its popularity in the industry.
Key Components:
Commercial air to water swimming heat pump is designed to cope with the demands of aquatic facilities, such as Municipalities, Hotels,Gymnasium, Resorts, Schools and wherever more than.
Heat generated by air source is cheap, eco-friendly, and reliable, so anyone can benefit from it.
This type of system is more efficient than traditional electric pool heater, as it uses the outside air to regulate the temperature inside the pool. It also helps to reduce energy costs and can help to reduce the carbon footprint of a facility.
Features:
Designed and widely applied for public pools
Fast return on investment
Heating & Cooling function
Inverter system
Corrosion proof titanium heat exchange Long life span
Multiple system protections-Safe and reliable operation
World brand compressor
Self-diagnosis-Displaying error code on control panel
Galvanized powered coated steel cabinet
Anti-freezing Protection
Higher Efficient:Heating/Cooling
By utilizing 4 ways valve, provide both heating and cooling mode to create more possibility for pool enjoyment.
Inverter Technology
Intelligent Inverter tech will keep the constant water temperature automatically, a much more convenient swimming experience than an ON/OFF system.
Eco Friendly Refrigerant R32
Compared to the refrigerants widely used today, such as R22 and R410a, R32 has a global warming potential that is two-third lower and it is remarkable for its low environmental impact, which speed up the its popularity in the industry.
Key Components:
Commercial air to water swimming heat pump is designed to cope with the demands of aquatic facilities, such as Municipalities, Hotels,Gymnasium, Resorts, Schools and wherever more than.
Heat generated by air source is cheap, eco-friendly, and reliable, so anyone can benefit from it.
This type of system is more efficient than traditional electric pool heater, as it uses the outside air to regulate the temperature inside the pool. It also helps to reduce energy costs and can help to reduce the carbon footprint of a facility.
CODE | WP65V | WP100V | WP115V | WP130V | |
Heating Performance Condition: Air 26ºC, Water 26ºC | |||||
Max. Heating Capacity (KW) | 64.0~16.0 | 96.0~24.0 | 113.0~28.3 | 127.0~31.8 | |
COP | 6.9~13.2 | 6.7~13.1 | 6.8~13.3 | 6.9~13.2 | |
Heating Performance Condition: Air 15ºC, Water 26ºC | |||||
Max. Heating Capacity (KW) | 46.6~11.7 | 69.9~17.5 | 82.3~20.6 | 92.5~23.1 | |
COP | 5.0~7.5 | 5.0~7.5 | 5.1~7.6 | 4.9~7.4 | |
Operating Air Temperature ºC | -10~43 | ||||
Power Supply (V/Hz) | 380V/3PH/50HZ | ||||
Rated Input Power(KW) | 9.3~1.2 | 14.3~1.8 | 16.6~2.1 | 18.5~2.4 | |
Rated Input Current(A) | 16.7 | 25.6 | 29.7 | 33.2 | |
Max Heating Current (A) | 21.7 | 33.3 | 38.7 | 43.1 | |
Water Flow Rate (m3/h) | 20~24 | 27~33 | 33~40 | 40~48 | |
Water Connection ( inch) | 2 | 2-1/2 | 2-1/2 | 3 | |
Sound level at 1m (dB(A)) | 50~64 | 51~65 | 51~65 | 53~69 | |
Net Dimension L*W*H(mm) | 1160*900*2065 | 1160*900*2065 | 1160*900*2065 | 2000*900*2065 | |
Qty per 20ft/40HQ(PCS) | 9/21 | 9/21 | 9/21 | 5/12 | |
Note:The data above subject to change without prior notice. |
CODE | WP65V | WP100V | WP115V | WP130V | |
Heating Performance Condition: Air 26ºC, Water 26ºC | |||||
Max. Heating Capacity (KW) | 64.0~16.0 | 96.0~24.0 | 113.0~28.3 | 127.0~31.8 | |
COP | 6.9~13.2 | 6.7~13.1 | 6.8~13.3 | 6.9~13.2 | |
Heating Performance Condition: Air 15ºC, Water 26ºC | |||||
Max. Heating Capacity (KW) | 46.6~11.7 | 69.9~17.5 | 82.3~20.6 | 92.5~23.1 | |
COP | 5.0~7.5 | 5.0~7.5 | 5.1~7.6 | 4.9~7.4 | |
Operating Air Temperature ºC | -10~43 | ||||
Power Supply (V/Hz) | 380V/3PH/50HZ | ||||
Rated Input Power(KW) | 9.3~1.2 | 14.3~1.8 | 16.6~2.1 | 18.5~2.4 | |
Rated Input Current(A) | 16.7 | 25.6 | 29.7 | 33.2 | |
Max Heating Current (A) | 21.7 | 33.3 | 38.7 | 43.1 | |
Water Flow Rate (m3/h) | 20~24 | 27~33 | 33~40 | 40~48 | |
Water Connection ( inch) | 2 | 2-1/2 | 2-1/2 | 3 | |
Sound level at 1m (dB(A)) | 50~64 | 51~65 | 51~65 | 53~69 | |
Net Dimension L*W*H(mm) | 1160*900*2065 | 1160*900*2065 | 1160*900*2065 | 2000*900*2065 | |
Qty per 20ft/40HQ(PCS) | 9/21 | 9/21 | 9/21 | 5/12 | |
Note:The data above subject to change without prior notice. |
